HomePlug AV2 Standard: Provides ultra-fast powerline transfer speeds of up to 1300 Mbps‡
AC1200 Dual-Band Wi-Fi: Extends ultra-fast dual-band Wi-Fi with speeds of up to 867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz†
OneMeshTM: Works with your OneMeshTM router to form a unified mesh network for seamless streaming while moving around your home
2 × 2 MIMO: Establishes multiple simultaneous connections for you to enjoy higher powerline speeds and greater stability
One-Touch Wi-Fi Configuration: One press of theWi-Fi button copies the network name and password from your router. Anysetting changes will be automatically applied to the entire Powerlinenetwork
Wi-Fi Auto-Sync: Add additional extenders to yourpowerline network by pair button, uniformly sync settings such as SSID, password, Wi-Fi Schedule and LED Schedule for all network devices
Plug and Play: Set up your powerline network and start enjoying fast, seamless wired/wireless connections in minutes
Extra Power Socket: Get power from the outlet for your other devices with the integrated power socket
3× Gigabit Ports - Provide secure wired networks for desktops, smart TVs or games consoles

ХАРДУЕРНИ ХАРАКТЕРИСТИКИ

Скорости на пренос на данни
Powerline: up to 1300 Mbps
Ethernet: 10/100/1000 Mbps

Transmission Distance
Up to 300 meters/1000 feet over existing electrical wiring

Стандарти и протоколи
HomePlug AV2
IEEE 1901
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.11b/g/n (2.4 GHz)
IEEE 802.11a/n/ac (5 GHz)

Съвместимост
Compatible with all HomePlug AV & HomePlug AV2 standard
powerline adapters

Тип контакт
EU

Интерфейс
3 Gigabit Ethernet Ports

Бутон
Pair
LED On/Off
Wi-Fi
Reset

Консумирана енергия
Maximum: 13.7W, Typical: 11W

LED
Power
Powerline
Ethernet
Wi-Fi (2.4 GHz)
Wi-Fi (5 GHz)

БЕЗЖИЧНИ ХАРАКТЕРИСТИКИ

Безжични стандарти
IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz

Честотa
2.4 GHz and 5 GHz

Скорост на сигнала
300 Mbps at 2.4 GHz, 867 Mbps at 5 GHz

СОФТУЕРНИ ХАРАКТЕРИСТИКИ

Mesh Technology
OneMesh Supported
Withoutreplacing your existing devices or buying a whole new WiFi ecosystem, OneMesh helps you create a more flexible network that covers yourentire home with TP-Link OneMesh products.

Качество на услугата
ToS
Supports up to 4-level type QoS
Support up to 8-level VLAN priority field

Защита
Wireless: WEP, WPA, WPA2, WPA3
Powerline: 128-bit AES Encryption

Управление
TP-Link tpPLC App, or download new tpPLC Utility on PCs.

Технология на модулация
OFDM

IGMP
IGMP v1/v2/v3

PHYSICAL

Dimensions (W×D×H)
3.0 × 1.7 × 6.0 in. (75 × 42 × 152 mm)

Package Content
AV1300 Gigabit Passthrough Powerline ac Wi-Fi Extender: 1× TL-WPA8631P
1× Ethernet Cables
1× Quick Installation Guide

ДРУГИ

Сертификати
CE, RoHS

Системни изисквания
System Requirements:
Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux

System Requirements for tpPLC Utility:
Windows 10/8.1/8/7/Vista/XP and Mac OS X (10.7 or later)

Околна среда
Operating Temperature: 0°C~40°C (32°F~104°F)
Operating Humidity: 10%~90% non-condensing



Продукт известен още и като TL WPA 8631 P, TLWPA8631P, TL WPA8631P, TL-W PA8631 P
